Burkert Gas Mass Flow Controller Model 8626 00182050
LEHIY item code: LH-0202
Quick buying check
This page helps you check Burkert Gas Mass Flow Controller Model 8626 00182050 before you ask for a quote.
Confirm the brand, model number, part number, and quantity. Share a clear nameplate photo when the old item has close variants.
LEHIY can check stock, lead time, packing, shipping documents, and safe replacement options for maintenance orders.
The German Burkert 8626 gas mass flow controller (model 00182050) has a flow rate of 800 NmL/min (argon), and supports air. It uses a 316 base with a G1/2 inch connector and operates at 4~20 mA.
The Burkert MFC gas mass flow controller (MFC) is originally from France, and all products are directly supplied by the Burkert factory.
We offer a 40% discount on prices, a one-year warranty period, repairs are available upon request.
All genuine Burkert gas mass flow controllers come with the original Burkert German factory shipping list and import customs documents, and each shipment includes a Burkert gas mass flow controller factory test report and instruction manual.
Our company specializes in the sales, installation, commissioning, and maintenance of German Burkert products in China, including solenoid valves, MFC/MFM, flow meters, controllers, proportional valves, pneumatic valves, sensors, regulating valves, angle seat valves, diaphragm valves, and diaphragm plates.
All Burkert products are guaranteed authentic, delivered promptly, and supported by pre-sales and after-sales services. Technical guidance on Burkert product selection is available; please purchase with confidence.
Type 8626 - German Burkert Gas Mass Flow Controller (MFC) Type Description: The German Burkert 8626 mass flow controller (MFC) is suitable for mass flow control of large volumes of gases. An inline thermal sensor located directly in the gas flow enables very fast response times.
A direct-acting Burkert proportional valve as the actuator ensures excellent responsiveness.
An integrated PI controller gives the Burkert MFC superior control characteristics. The Burkert 8626 gas mass flow controller can be calibrated for two different gases, and users can switch between them. As an electrical interface, it provides both analog standard signals and fieldbus.
Due to its resistance to contamination and high IP protection rating, the 8626 Burkert mass flow controller is particularly suitable for applications in harsh environments.
Burkert mass flow controllers from Germany have a wide range of applications, including burner control, heat treatment, metallurgy, food industry, environmental technology, material coating, fuel cell technology, and test benches.
Burkert Gas Mass Flow Controller Model 8626 Features: Nominal flow range from 20 lN/min to a maximum of 1500 lN/min; High measurement accuracy and repeatability; Fast control speed; IP65 protection rating. Optional: Fieldbus interface. Burkert Gas Mass Flow Controller Model 8626
- Flow Rate 800 N/min (Ar).
- Technical Specifications: Type 8626 / Product Number 182050 Controller | Ar | 800.00 N/min | 24V DC | Internal thread - G1/2" | 4-20 mA Medium and Calibration: Mounting position horizontal;
- Work area medium 1 800 Unit medium 1 N/min;
- Operating medium 1 Ar;
- Calibration medium 1 Real gas calibration;
- Calibration pressure medium 1 at Qnom 7 Materials: Fluidics body material Aluminum;
- Sealing material FKM (Fluor rubber) Sealing toward outside material FKM (Fluor rubber) Characteristics Type 8626 Device function Controller Input/Output Input type digital quantity 3 PCE Output type digital quantity 2 PCE Measuring or control range 1:50 Process connection type/diameter Port connection 1 DN 1/2" Port connection 1 type Internal thread Port connection 1 standard G Voltage/Current Supply voltage 24 V DC Process pressure/Temperature Outlet pressure medium 1 at Qnom 4 Kv value Seat size 6 mm (1/4") Electrical connection 1 type D-SUB Electrical connection 2 type Female connector M16 Software/Communication Input signal 4-20 mA Output signal 4-20 mA Actuator type 2836 Protection type (IP max. with suitable connector) IP65 Burkert Gas Mass Flow Controller (MFC) German company BorgDee Fluid Control Systems offers superior Burkert gas mass flow controllers (MFC) and Burkert gas mass flow meters (MFM), widely used in biopharmaceutical and petrochemical industries. Burkert mass flow controllers are known for their high precision, fast response, and stable flow rates. BorgDee also provides Burkert mass flow meters for both gas and liquid applications, meeting higher precision requirements in liquid control. Further search keywords: German BorgDee flow controller, BURKERT flow controller, BorgDee flow controller, BURKERT gas flow meter, BURKERT MFC flow controller, German Burkert gas controller, Burkert mass flow controller, Burkert mass flow meter MFM.
Plain language sourcing guide for Burkert Gas Mass Flow Controller Model 8626 00182050
Start with the full model name. Check the brand name. Check the part number. Check the code on the old unit. These small checks help you avoid a wrong order.
Take one clear photo of the front label. Take one photo of the side label. If the part has a cable, plug, port, seal, coil, or screen, take a photo of that area too.
Tell us the quantity you need. Tell us your country. Tell us the date when the plant needs the part. We can then check stock, lead time, safe packing, and the best shipping plan.
If the exact model is no longer made, do not guess. Send the old model and the use case. LEHIY can compare close options and explain which choice is safer for repair work.
Use simple order notes. Write the model in one line. Write the quantity in one line. Write the delivery country in one line. This helps our team reply faster.
Check the old part before removal. Look at the label. Look at the connector. Look at the mounting size. Look at the voltage or pressure rating if it is shown.
Do not rely on a short nickname for a part. Many industrial items have close versions. A small suffix can change the plug, output, range, or software setting.
Ask for a stock check if the plant is stopped. Ask for a lead time if the order is planned. Ask for packing photos if the part is fragile or heavy.
For a replacement order, tell us what failed. Tell us where the part is used. Tell us if an equal model is acceptable. This makes the first answer more useful.
For repeat orders, send the last invoice, old label, or old packing photo. The same reference can help us match the correct product again.
For urgent service, keep the message simple. One model, one quantity, one photo, and one delivery target are enough for a fast first check.
Share Article
| Brand Name: | Burkert | Certification: | ISO9001, CE |
|---|---|---|---|
| Place of Origin: | China | Condition: | New |
| Warranty: | 1 year | Customized sourcing: | available |
