Burkert pressure sensor transmitters: 8316-563782
LEHIY item code: LH-0149
Quick buying check
This page helps you check Burkert pressure sensor transmitters: 8316-563782 before you ask for a quote.
Confirm the brand, model number, part number, and quantity. Share a clear nameplate photo when the old item has close variants.
LEHIY can check stock, lead time, packing, shipping documents, and safe replacement options for maintenance orders.
We are an authorized distributor of Burkert pressure transmitters, model 8316-563782, with a pressure range of 0-40 bar and a 4-20mA output. It features a 5-pin M12 electrical connection
- . LEHIY Industrial is a leading distributor of Burkert transmitters, offering upgrades from the Burkert 8314 pressure sensor to the 8316 model. All Burkert pressure sensors and transmitters are shipped directly from the Burkert factory in Germany via air freight. We provide detailed shipping lists and import customs documents. Our products come with a one-year warranty and offer testing, repair, and replacement services. For more information on popular Burkert 8316 pressure transmitter models, please see: Burkert 8314 upgrade 8316, 0-10 bar, 4-20mA output, models 563780, 563781, and 563778. BURKERT Pressure Sensor Transmitter 8316 Type Description: The BURKERT 8316 pressure sensor transmitter is a compact pressure measurement device that combines mechanical strength, EMC characteristics, and operational reliability. It is particularly suitable for demanding industrial applications. Because stainless steel is not resistant to corrosive media, a PVDF process interface can be used. Features of the BURKERT Pressure Sensor Transmitter 8316: Dual-wire version with ceramic/thick film measuring unit for 4...20mA output;
- Compact and stable design ensures optimal operational reliability. BURKERT Pressure Sensor Transmitter 8316-563782 Technical Specifications: Sensing element: Ceramic element;
- Measurement range: 0-1, 4, 6, 10, 16, 40 or 100 bar;
- Process connection: G 1/4" external thread, conforming to DIN 3852;
- Electrical connection: M12 x 1 plug;
- Overload: 3 times full scale (0-4 bar);
- 5 times full scale (6-100 bar);
- Burst pressure: 3 times full scale (0-4 bar);
- 5 times full scale (6-100 bar);
- Patented media stop system prevents media leakage when burst pressure is exceeded. Measurement accuracy relative to pressure measurement: The sum of linearity, hysteresis, and repeatability: Zero and full-scale balance accuracy: ≤ 0.3% of full scale. Dynamic response: Suitable for both static and dynamic measurements. Response time less than 2ms, typical response time: 1ms. Protection rating: IP67. Body material: Stainless steel 1.4305 AISI 303. Wetted parts material: Ceramic (Al2O3), Stainless steel 1.4305 (1.4404 AISI 316L available upon request), FKM seal, PPS. BURKERT Pressure Sensor Transmitter 8316 Model 563782. Medium temperature: -15 to 125℃. Ambient temperature: -15 to 85℃. Temperature coefficient: ≤ 0.015%/℃ of full scale. Installation: Can be installed as needed, preferably with the pressure port facing down. Power supply (U): 8-33 V DC, unrectified output signal (2-wire). Standard 4-20 mA signal resistive load: < (U - 8 V) / Interference emission: 0.02 A;
- Complies with EN 50081-1 and EN 55022;
- Interference stability: Complies with EN 50082-2;
- Protection: Short circuit protection, reverse polarity protection, and overvoltage protection. For more information on the selection and specifications of the BURKERT 8316 pressure sensor transmitter, please call [phone number].
Plain language sourcing guide for Burkert pressure sensor transmitters: 8316-563782
Start with the full model name. Check the brand name. Check the part number. Check the code on the old unit. These small checks help you avoid a wrong order.
Take one clear photo of the front label. Take one photo of the side label. If the part has a cable, plug, port, seal, coil, or screen, take a photo of that area too.
Tell us the quantity you need. Tell us your country. Tell us the date when the plant needs the part. We can then check stock, lead time, safe packing, and the best shipping plan.
If the exact model is no longer made, do not guess. Send the old model and the use case. LEHIY can compare close options and explain which choice is safer for repair work.
Use simple order notes. Write the model in one line. Write the quantity in one line. Write the delivery country in one line. This helps our team reply faster.
Check the old part before removal. Look at the label. Look at the connector. Look at the mounting size. Look at the voltage or pressure rating if it is shown.
Do not rely on a short nickname for a part. Many industrial items have close versions. A small suffix can change the plug, output, range, or software setting.
Ask for a stock check if the plant is stopped. Ask for a lead time if the order is planned. Ask for packing photos if the part is fragile or heavy.
For a replacement order, tell us what failed. Tell us where the part is used. Tell us if an equal model is acceptable. This makes the first answer more useful.
For repeat orders, send the last invoice, old label, or old packing photo. The same reference can help us match the correct product again.
For urgent service, keep the message simple. One model, one quantity, one photo, and one delivery target are enough for a fast first check.
Share Article
| Brand Name: | Burkert | Certification: | ISO9001, CE |
|---|---|---|---|
| Place of Origin: | China | Condition: | New |
| Warranty: | 1 year | Customized sourcing: | available |
What are your strengths?
Ans. LEHIY specializes in industrial automation and control components, offering fast sourcing, stable quality, and competitive prices for global customers.
What is your estimated delivery time?
Ans. Most items ship within 3-7 days. Customized or rare models may take 10-30 working days.
What are your primary product offerings?
Ans. Our main products include PLCs, sensors, valves, solenoid valves, actuators, power modules, transmitters, and complete industrial automation solutions.
How can I get in touch with you?
Ans. You can reach us anytime via Email, WhatsApp, LinkedIn, or our contact page. Our sales engineers respond quickly and provide technical support when needed.
What are your payment terms?
Ans. Standard terms are 50% TT in advance and 50% balance before delivery. We also support Alibaba Trade Assurance and L/C for qualified orders.
Feel free to Ask questions
Replacement support
Burkert pressure sensor transmitters: 8316-563782
Send the brand, model, part number, quantity, nameplate photos, and application requirements. LEHIY will check availability, suitable alternatives, packing details, and delivery options before quoting.
For discontinued, temporarily unavailable, or configuration-sensitive items, our team can compare the requested model with close variants or compatible replacements for maintenance and spare parts planning.
Use this page as a practical sourcing note for engineers, buyers, and maintenance teams comparing automation components. Check the model name, brand, LEHIY code, application, and replacement requirements before sending an inquiry.
Short, clear information helps our team confirm availability faster and reduce back-and-forth communication during urgent maintenance projects.
- Confirm the complete model number and any suffix printed on the nameplate.
- Share quantity, destination country, preferred shipping method, and target delivery date.
- Include photos, drawings, old purchase records, or datasheets when compatible alternatives are acceptable.
- Ask for stock checking, replacement comparison, packing details, and export documentation before ordering.
Useful details for a faster quote
- Complete model and part number
- Required quantity and target delivery date
- Nameplate photos, drawings, or old purchase records
- Voltage, signal range, dimensions, or accessory needs
Model matching
We review brand, model, part number, nameplate photos, installation environment, and replacement requirements.
Quality and delivery
Each order can be checked for authenticity, condition, packing, warranty, shipping method, and delivery schedule.
Stock alternatives
For urgent maintenance projects, we can help check stock, compatible alternatives, and fast international shipment.
Burkert pressure sensor transmitters: 8316-563782 verification notes
Please send the full model number, quantity, target delivery date, and nameplate photos. These details help us check the requested product or a close replacement.
LEHIY reviews product name, part number, series, label information, and application requirements before shipment.
If the original model is discontinued or supplied with different accessories, we can explain practical differences before quoting.
For repeat purchasing, we can help organize related models, replacement parts, shipment schedules, and clear communication for your team.
