Burkert proportional solenoid valves 2873|2875 are authorized distributors.
LEHIY item code: LH-0136
Quick buying check
This page helps you check Burkert proportional solenoid valves 2873|2875 are authorized distributors. before you ask for a quote.
Confirm the brand, model number, part number, and quantity. Share a clear nameplate photo when the old item has close variants.
LEHIY can check stock, lead time, packing, shipping documents, and safe replacement options for maintenance orders.
LEHIY Industrial, an distributor of Burkert proportional solenoid valves, offers the widely used Burkert 2873/2875 models. These valves are not only compatible with Burkert digital controllers to achieve proportional valve opening, but also with Burkert MFC series mass flow controllers to regulate flow rate.
Made in France, these Burkert proportional solenoid valves come with a one-year warranty.
LEHIY Industrial has a strong advantage as a authorized distributor of Burkert proportional solenoid valves, working directly with the Burkert German factory for many years, offering competitive discounts, fast delivery, and original factory support for selection and after-sales service!
Burkert proportional solenoid valve product introduction: Based on the principle of spring-operated solenoid valves that close upon de-energization, the German Burkert proportional solenoid valve achieves a balance between spring force and electromagnetic force from the coil current by modifying the structure of the electromagnetic components.
The valve stroke and/or valve opening are determined by the magnitude of the coil current and/or electromagnetic force. The valve opening is directly proportional to the electromagnetic force.
Burkert's proportional solenoid valves, supplied by Burkert's office, are controlled by a pulse width modulation (PWM) signal, which causes the coil current to vary according to a set value. and maximum flow rates under operating conditions.
Burkert proportional solenoid valves can be used to implement both open-loop and closed-loop control loops. Open-loop loops do not require actual value feedback, while closed-loop control loops adjust based on the deviation between the set value and the actual value.
Types of Burkert proportional solenoid valves from Germany include: 6020, 6024, 6223, 2871, 2873, 2875, 2836, 2861, 2863, and 2865.
A key characteristic of Burkert proportional solenoid valve positioning performance is hysteresis: the maximum difference in output signal as the input signal changes from small to large and from large to small, expressed as a percentage of the maximum output signal.
- Response Sensitivity: The minimum setpoint difference that causes a change in the output signal, expressed as a percentage of the maximum output signal. - Repeatability: The maximum deviation of the output signal when an input signal of the same magnitude is applied repeatedly in the same direction.
- Control Ratio: The ratio of the Kv values at the maximum and minimum opening (see calculation for proportional valves). The control ratio of German Burkert proportional solenoid valves can reach 1:500.
Burkert proportional solenoid valves can be controlled using either the Burkert 8605 controller or the Burkert 8611 universal controller.
In principle, the Burkert 8605 controller converts the analog setpoint signal at the input into a corresponding pulse-width modulated (PWM) signal output, which controls the proportional solenoid valve.
Furthermore, the Burkert 8605 controller features current regulation to compensate for coil heating, adapts the minimum and maximum coil current to the applied pressure conditions, zero-point cutoff, and ramp functions.
The Burkert 8611 universal controller can control process values such as temperature and frequency, or output a PWM signal to control the Burkert proportional solenoid valve.
Combination types of Burkert controllers and Burkert proportional solenoid valves: Position setpoint: Burkert 8605 controller plug-in type, Burkert 8605 controller DIN rail mounted type; Process setpoint and actual process value: Burkert 8611 general-purpose controller.
Burkert proportional solenoid valve selection guide: To ensure five-fault control functionality, the Burkert proportional valve must be selected according to its application. The most important selection parameters are the Kv value and pressure range.
The Kv value (unit: m³/h) of German Burkert valves is measured with water as the medium, at 20°C, with an inlet pressure of 1 bar and an outlet pressure of 0 bar. For gases, it is usually expressed as the QNn value.
The QNn value is the flow rate (lN/min) of air at 20°C, with a valve inlet pressure of 6 bar and a valve pressure drop of 1 bar.
The reference conditions for gas are an absolute pressure of 1.013 bar and a temperature of 0°C. In addition to the Kv value, the maximum pre-pressure at the valve inlet is also a major factor in valve selection (model and nominal diameter).
The smaller the pipe diameter or the larger the coil of a Burkert valve, the higher the maximum switching pressure.
The Kv value can be calculated using the Following formula. Based on the calculated Kv value and the actual pressure range, the Burkert valve model can be found in the selection guide.
We are an authorized distributor of Burkert proportional solenoid valves, specifically models 2873 and 2875, with stock available (models 239088, 239089, 316530, etc.).
Hot-selling models of German Burkert proportional solenoid valves and matching Burkert controllers include: Burkert 2875 proportional solenoid valve 4mm G3/8 brass 239088, 2875-A-04,0-FF-MS-GM83-024/DC-16 (in stock); Burkert 2875 proportional solenoid valve 4mm G3/8 stainless steel 239089,.
2875-A-04,0-FF-VA-GM83-024/DC-16 (in stock).
Burkert 8605 digital controller 316530 is in stock!
Burkert 2875 proportional solenoid valve 00236922, Burkert 2875 proportional valve 00255726, 2875 A 4.0 FKM MS G1/2 24VDC 16W PWM400-500Hz, Burkert 2875 proportional solenoid valve 00239040, Burkert electrically controlled back pressure valve 2875:323875 (G1/2, 6mm, 12V, stainless steel), Burkert 2875 proportional solenoid valve 00274998, Burkert.
DS2875 proportional valve 24VDC 0-20BAR, 2mm diameter, EPDM sealing material, PWM400-500HZ, base plate connection with connector plug 00257366.
Burkert 2875 proportional solenoid valve with 8605 controller G3/8" range 40-400L/H. Order No.: 236905+316530.
Burkert German Burkert 2873 proportional solenoid valve with Burkert 8605 controller: G1/4 100L flow rate 234297+316530; G1/4 range 100L/H; G1/4 250L flow rate proportional 234303+316530; G1/4" range 20-250L/H. Burkert 2873 proportional valve 00234314; Burkert 2873 proportional valve 00239084.
Burkert 2873 proportional valve 00239082; Burkert 2871 proportional solenoid valve 00330529; Burkert 2871 proportional solenoid valve 00265641; Burkert 2871 proportional valve 255617+2507 plug 423845; Burkert 6027 proportional solenoid valve 00178247; Burkert 6024 proportional valve 150406; Burkert 0263 proportional solenoid valve 00002606; Burkert 8605 digital controller 00316532; Burkert 8605 digital.
controller 00178356 upgraded to 00316529.
Baode Valves is an authorized distributor of Burkert proportional solenoid valves, also known as Burkert proportional valves, Burkert solenoid control valves, Burkert solenoid proportional valves, etc.
Plain language sourcing guide for Burkert proportional solenoid valves 2873|2875 are authorized distributors.
Start with the full model name. Check the brand name. Check the part number. Check the code on the old unit. These small checks help you avoid a wrong order.
Take one clear photo of the front label. Take one photo of the side label. If the part has a cable, plug, port, seal, coil, or screen, take a photo of that area too.
Tell us the quantity you need. Tell us your country. Tell us the date when the plant needs the part. We can then check stock, lead time, safe packing, and the best shipping plan.
If the exact model is no longer made, do not guess. Send the old model and the use case. LEHIY can compare close options and explain which choice is safer for repair work.
Use simple order notes. Write the model in one line. Write the quantity in one line. Write the delivery country in one line. This helps our team reply faster.
Check the old part before removal. Look at the label. Look at the connector. Look at the mounting size. Look at the voltage or pressure rating if it is shown.
Do not rely on a short nickname for a part. Many industrial items have close versions. A small suffix can change the plug, output, range, or software setting.
Ask for a stock check if the plant is stopped. Ask for a lead time if the order is planned. Ask for packing photos if the part is fragile or heavy.
For a replacement order, tell us what failed. Tell us where the part is used. Tell us if an equal model is acceptable. This makes the first answer more useful.
For repeat orders, send the last invoice, old label, or old packing photo. The same reference can help us match the correct product again.
For urgent service, keep the message simple. One model, one quantity, one photo, and one delivery target are enough for a fast first check.
Share Article
| Brand Name: | Burkert | Certification: | ISO9001, CE |
|---|---|---|---|
| Place of Origin: | China | Condition: | New |
| Warranty: | 1 year | Customized sourcing: | available |
What are your strengths?
Ans. LEHIY specializes in industrial automation and control components, offering fast sourcing, stable quality, and competitive prices for global customers.
What is your estimated delivery time?
Ans. Most items ship within 3-7 days. Customized or rare models may take 10-30 working days.
What are your primary product offerings?
Ans. Our main products include PLCs, sensors, valves, solenoid valves, actuators, power modules, transmitters, and complete industrial automation solutions.
How can I get in touch with you?
Ans. You can reach us anytime via Email, WhatsApp, LinkedIn, or our contact page. Our sales engineers respond quickly and provide technical support when needed.
What are your payment terms?
Ans. Standard terms are 50% TT in advance and 50% balance before delivery. We also support Alibaba Trade Assurance and L/C for qualified orders.
Feel free to Ask questions
Replacement support
Burkert proportional solenoid valves 2873|2875 are authorized distributors.
Send the brand, model, part number, quantity, nameplate photos, and application requirements. LEHIY will check availability, suitable alternatives, packing details, and delivery options before quoting.
For discontinued, temporarily unavailable, or configuration-sensitive items, our team can compare the requested model with close variants or compatible replacements for maintenance and spare parts planning.
Use this page as a practical sourcing note for engineers, buyers, and maintenance teams comparing automation components. Check the model name, brand, LEHIY code, application, and replacement requirements before sending an inquiry.
Short, clear information helps our team confirm availability faster and reduce back-and-forth communication during urgent maintenance projects.
- Confirm the complete model number and any suffix printed on the nameplate.
- Share quantity, destination country, preferred shipping method, and target delivery date.
- Include photos, drawings, old purchase records, or datasheets when compatible alternatives are acceptable.
- Ask for stock checking, replacement comparison, packing details, and export documentation before ordering.
Useful details for a faster quote
- Complete model and part number
- Required quantity and target delivery date
- Nameplate photos, drawings, or old purchase records
- Voltage, signal range, dimensions, or accessory needs
Model matching
We review brand, model, part number, nameplate photos, installation environment, and replacement requirements.
Quality and delivery
Each order can be checked for authenticity, condition, packing, warranty, shipping method, and delivery schedule.
Stock alternatives
For urgent maintenance projects, we can help check stock, compatible alternatives, and fast international shipment.
Burkert proportional solenoid valves 2873|2875 are authorized distributors. verification notes
Please send the full model number, quantity, target delivery date, and nameplate photos. These details help us check the requested product or a close replacement.
LEHIY reviews product name, part number, series, label information, and application requirements before shipment.
If the original model is discontinued or supplied with different accessories, we can explain practical differences before quoting.
For repeat purchasing, we can help organize related models, replacement parts, shipment schedules, and clear communication for your team.
