Moog G761-3033B Servo Valve, Genuine G761 Electro-hydraulic Valve
LEHIY item code: LH-MOOG-0005
Quick buying check
This page helps you check Moog G761-3033B Servo Valve, Genuine G761 Electro-hydraulic Valve before you ask for a quote.
Confirm the brand, model number, part number, and quantity. Share a clear nameplate photo when the old item has close variants.
LEHIY can check stock, lead time, packing, shipping documents, and safe replacement options for maintenance orders.
Brand new Moog G761-3033B servo valves, genuine G761 electro-hydraulic servo valves, sourced directly from authorized dealers. Quality guaranteed. All Moog servo valves are renowned for their high accuracy and reliable operation, even in demanding industrial applications.
The Moog G761 series servo valves are high-performance, two-stage flow control valves suitable for electro-hydraulic position, speed, pressure, or force servo control systems with high dynamic response requirements.
The MOOG G761/-761 series electro-hydraulic servo valves are simple, robust, reliable, and long-lasting, suitable for various applications.
They are among the most versatile MOOG servo valves and the latest model in the well-known 760 series. This series embodies nearly 70 years of Moog's professional design expertise.
Moog G761-3033B electro-hydraulic servo valve introduction: The Moog G761-3033B servo valve adopts a T-type, cross-throttling four-way flow control valve for better control performance.
This valve series is a high-performance anode electro-hydraulic servo valve with rated flow rates ranging from 7 MPa to 4 L/min to 63 L/min. The pilot stage is a symmetrical double-nozzle baffle valve driven by a dry torque motor with double air gaps.
The output stage is a cross-spool valve. The spool position is mechanically fed back by a cantilever spring rod.
This series of valves features a simple, robust, reliable structure and long service life. This valve is suitable for position, speed, and force (or pressure) servo control systems, providing high dynamic response.
Features of the MOOG G761-3033B servo valve: Utilizes a dry torque motor and two-stage hydraulic amplifier structure; a frictionless double-nozzle baffle valve with high spool driving force, excellent dynamic response, and robust construction.
High resolution, low-altitude stall, factory-adjusted, selectable fifth oil zone, independent pilot valve control, and field-replaceable disc oil filter for the pilot valve. The actual flow through the MOOG servo valve is related to the magnitude of the input current signal and the valve's pressure drop.
The working principle of the genuine MOOG G761-3033B servo valve: After the torque motor coil of the MOOG servo valve receives an input current command signal, the electromagnetic force acts on both ends of the distance iron, causing the distance iron to induce the baffle inside the spring tube.
to deflect.
The deflection of the baffle reduces the flow in the nozzle, changes the pressure on the valve core side connected to the nozzle, and causes the valve core to move to one side.
When an electrical signal is input to the servo amplifier, the armature coil of the torque motor will flow current, generating a magnetic field.
Under the action of the magnets on both sides, a rotational torque is generated, rotating the armature and moving the connected baffle, which extends to the middle of the two nozzles.
Under normal and stable working conditions, if the distance between the two sides of the baffle and the nozzle is the same, making the drainage area of the side nozzles the same, then the oil pressure on both sides of the nozzle is the same.
The displacement of the MOOG servo valve core opens the passage between the supply port (P) and the control port, and transmits oil through the return port (T) and other control ports.
Simultaneously, the displacement of the valve core applies a force to the spring load, which generates a response torque on the armature baffle assembly.
If this response torque balances the torque exerted by the electromagnetic force of the torque motor on the armature baffle, the baffle will return to zero, and the sliding valve core will remain in the open position in this balanced state until the input constant signal changes.
Common models of the Moog G761 electro-hydraulic servo valve include: G761-3033B, G761-3034B, G761-3002B, G761-3004B, G761-3005B, G761-3006B, and G761-3008B.
Plain language sourcing guide for Moog G761-3033B Servo Valve, Genuine G761 Electro-hydraulic Valve
Start with the full model name. Check the brand name. Check the part number. Check the code on the old unit. These small checks help you avoid a wrong order.
Take one clear photo of the front label. Take one photo of the side label. If the part has a cable, plug, port, seal, coil, or screen, take a photo of that area too.
Tell us the quantity you need. Tell us your country. Tell us the date when the plant needs the part. We can then check stock, lead time, safe packing, and the best shipping plan.
If the exact model is no longer made, do not guess. Send the old model and the use case. LEHIY can compare close options and explain which choice is safer for repair work.
Use simple order notes. Write the model in one line. Write the quantity in one line. Write the delivery country in one line. This helps our team reply faster.
Check the old part before removal. Look at the label. Look at the connector. Look at the mounting size. Look at the voltage or pressure rating if it is shown.
Do not rely on a short nickname for a part. Many industrial items have close versions. A small suffix can change the plug, output, range, or software setting.
Ask for a stock check if the plant is stopped. Ask for a lead time if the order is planned. Ask for packing photos if the part is fragile or heavy.
For a replacement order, tell us what failed. Tell us where the part is used. Tell us if an equal model is acceptable. This makes the first answer more useful.
For repeat orders, send the last invoice, old label, or old packing photo. The same reference can help us match the correct product again.
For urgent service, keep the message simple. One model, one quantity, one photo, and one delivery target are enough for a fast first check.
Share Article
| Brand Name: | MOOG | Certification: | ISO9001, CE |
|---|---|---|---|
| Place of Origin: | China | Condition: | New |
| Warranty: | 1 year | Customized sourcing: | available |
