Panasonic EX-13EA Ultra-thin Through-beam Type
LEHIY item code: LH-0079
Quick buying check
This page helps you check Panasonic EX-13EA Ultra-thin Through-beam Type before you ask for a quote.
Confirm the brand, model number, part number, and quantity. Share a clear nameplate photo when the old item has close variants.
LEHIY can check stock, lead time, packing, shipping documents, and safe replacement options for maintenance orders.
Product Overview
Panasonic Photoelectric Sensor, EX-13EA
Technical Specifications
| Item | Content |
|---|---|
| Model | EX-13EA |
| Detection Distance | 500mm |
| Minimum Detectable Object | ø2mm opaque object (completely light-blocking object) (Set distance between projector and receiver 500mm) |
| Hysteresis | - |
| Repeatability (perpendicular to detection axis) | Below 0.05mm |
| Power Supply Voltage | 12～24V DC±10% Pulse P-P below 10% |
| Current Consumption | Shine Transmitter: Below 10mA Shine Receiver: Below 10mA |
| Output | NPN Open Collector Transistor ・Maximum Inflow Current: 50mA ・Applied Voltage: 30V DC or lower (between output and 0V) ・Residual voltage: 2V or lower (current 50mA), 1V or lower (current 16mA) |
| Output: Short circuit protection | Equipped |
| Response time | Less than 0.5ms |
| Operating status indicator | Orange LED (lights up when output is ON) |
| Incident light indicator | - |
| Stable indicator | Green LED (lights up when stable incident light, when stable non-incident light) |
| Environmental Resistance: Protective Construction | IP67 (IEC), Leak-proof (JIS) |
| Environmental Resistance: Operating Temperature | -25～+55℃ (Avoid condensation and freezing), Storage: -30～+70℃ |
| Environmental Resistance: Operating Humidity | 35～85%RH, Storage: 35～85%RH |
| Environmental Resistance: Operating Illuminance | Incandescent Lamp: Illuminance of the illuminated surface below 3000R |
| Environmental Resistance: Voltage Withstand | AC1000V for 1 minute | Between all power connection terminals and the housing.
| Environmental resistance: Insulation resistance | High resistance meter based on DC250V, above 20MΩ, between all power connection terminals and the housing. |
| Environmental resistance: Vibration resistance | Frequency 10～500Hz, Dual amplitude 3mm (MAX. 20G), 2 hours each in X, Y and Z directions. |
| Environmental resistance: Shock resistance | Durability 500m/s<sup>2</sup> (approx. 50G), 3 cycles in each XYZ direction. |
| Light projection element | Red LED (peak wavelength: 680nm, modulated) |
| Material | Shell: Polyarylate Lens: Polyarylate |
| Cable | 0.1mm<sup>2</sup>3-core (sunlight transmitter: 2-core) rubber cable, 2m long |
| Cable Extension | Cables of 0.3mm<sup>2</sup> and above can be extended to 50m in total length (1 for both the light transmitter and receiver) |
| Weight | Body weight: Approximately 20g each for the light transmitter and receiver Packaging weight: Approximately 50g |
Product Dimensions Dimensions
Unit: mm
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Panasonic |
| Category | Photoelectric Sensors |
Plain language sourcing guide for Panasonic EX-13EA Ultra-thin Through-beam Type
Start with the full model name. Check the brand name. Check the part number. Check the code on the old unit. These small checks help you avoid a wrong order.
Take one clear photo of the front label. Take one photo of the side label. If the part has a cable, plug, port, seal, coil, or screen, take a photo of that area too.
Tell us the quantity you need. Tell us your country. Tell us the date when the plant needs the part. We can then check stock, lead time, safe packing, and the best shipping plan.
If the exact model is no longer made, do not guess. Send the old model and the use case. LEHIY can compare close options and explain which choice is safer for repair work.
Use simple order notes. Write the model in one line. Write the quantity in one line. Write the delivery country in one line. This helps our team reply faster.
Check the old part before removal. Look at the label. Look at the connector. Look at the mounting size. Look at the voltage or pressure rating if it is shown.
Do not rely on a short nickname for a part. Many industrial items have close versions. A small suffix can change the plug, output, range, or software setting.
Ask for a stock check if the plant is stopped. Ask for a lead time if the order is planned. Ask for packing photos if the part is fragile or heavy.
For a replacement order, tell us what failed. Tell us where the part is used. Tell us if an equal model is acceptable. This makes the first answer more useful.
For repeat orders, send the last invoice, old label, or old packing photo. The same reference can help us match the correct product again.
For urgent service, keep the message simple. One model, one quantity, one photo, and one delivery target are enough for a fast first check.
Share Article
| Brand Name: | Panasonic | Certification: | ISO9001, CE |
|---|---|---|---|
| Place of Origin: | China | Condition: | New |
| Warranty: | 1 year | Customized sourcing: | available |
