CDR pump UCL40-25-160 Italian CDRPompe centrifugal pump
LEHIY item code: LH-OTHER-0030
Quick buying check
This page helps you check CDR pump UCL40-25-160 Italian CDRPompe centrifugal pump before you ask for a quote.
Confirm the brand, model number, part number, and quantity. Share a clear nameplate photo when the old item has close variants.
LEHIY can check stock, lead time, packing, shipping documents, and safe replacement options for maintenance orders.
CDR pump UCL40-25-160, Italian CDR Pompe centrifugal pump, competitive pricing, fast delivery, and guaranteed quality. We are an authorized distributor of Italian CDR Pompe pumps, including centrifugal pumps, drive pumps, mechanical seals, acid/alkali centrifugal pumps, and vortex pumps.
We are a CDR centrifugal pump distributor and source directly from the Italian manufacturer. Features of the CDR Pompe centrifugal pump UCL: - Single-stage process centrifugal pump with mechanical seals coated with plastic and fluoroplastic materials. - Available materials: PP (polypropylene), PVDF (polyvinyl fluoride), PFA (perfluoroalkoxy).
- Versatility: Suitable for corrosive hazardous liquids (slightly contaminated, clean, low viscosity). - Reliability: Different types of mechanical seals can be installed on UCL pumps. Redesigned bearing housings ensure longer service life even under critical service conditions. - Design: UCL pumps feature the same hydraulic system as the magnetic drive series.
CDR UCL40-25-160 CDR Pompe Centrifugal Pump Characteristics: Sealing System: Mechanical Seal Design: EN 22858; ISO 2858 Standard: ISO 5199 Body Material: PFA liner - PVDF liner - PP liner Impeller Type: Closed or radial Fluid Temperature Range: PP: -10°C/+70°C PVDF: -15°C/+100°C PFA:.
-30°C/+120°C Flow Range @ 2900 RPM: 100 m³/h Head @ 2900 RPM: 68 m Viscosity Range: 1 cSt - 60 cSt Italian CDR Centrifugal Pump UCN-L100 Product Introduction: Discharge Diameter: 80 (mm) Head: 65 (m) Suction Diameter: 80 (mm) Impeller Structure: Closed impeller structure Principle:.
Jet pump Number of impellers: 3 Pump shaft position: Horizontal Material: Cast steel Impeller suction method: Single suction Model: UCN-L100 Flow rate: 110 (m³/h) Brand: CDR Application: Pipeline pump Shaft power: 18.5 (kW) Performance: Corrosion resistant NPSH: 10 (m) Italian CDR Centrifugal Pump ETS Series / Italian.
CDR Centrifugal Pump ETN Series Discharge port diameter: 100 (mm) Head: 100 (m) Impeller Structure: Open impeller Suction port diameter: 100 (mm) Structural principle: Jet pump Number of impellers: 3 Pump shaft position: Horizontal Material: Cast iron Impeller suction method: Double suction Model: ENS100 Flow rate: 24 (m³/h) Brand:.
CDR Application: Pipeline pump Shaft power: 100 (kW) Performance: Corrosion resistant NPSH: 1 (m) Italian CDR Centrifugal Pump UCN Series Discharge Diameter: 100 (mm) Head: 100 (m) Impeller Structure: Open Impeller Suction Diameter: 100 (mm) Structural Principle: Jet Pump Number of Impellers: 3 Pump Shaft Position: Horizontal Material: Cast Iron.
Impeller Suction Method: Double Suction Model: UCN 100 Flow Rate: 56 (m3/h) Brand: CDR Application: Pipeline Pump Shaft Power: 100 (kW) Performance: Corrosion Resistant Net Positive Suction Head (NPSH): 1 (m) Agent CDR Pump UCL40-25-160 Italian CDR Pompe Centrifugal Pump Field Nameplate: CDR Pump Italian CDR Pompe.
Centrifugal Pump UCL40-25-160 Technical Parameters and Structural Dimensions: Main Applications of Italian CDR Pompe Centrifugal Pump: Suitable for pumping corrosive, hazardous (slightly contaminated, clean, low viscosity) liquids in the chemical, petrochemical and pharmaceutical industries.
Product Introduction: A significant milestone in CDR's development was the commencement of production of plastic and CDR metal magnetically driven pumps in 1978. The company changed its name to "SRL" in 1985, and after several years became "SRL" again in 1992. CDR achieved ISO 9001 certification in 1999.
CDR's significant growth over the years has been driven by a genuine reputation based on the reliability, fairness, and advice of our products, including high-quality, reliable, and competitively priced products, successful applications, and excellent service.
As a family business, we believe these qualities are the value we offer to our customers, and we let our hard work speak for itself. Our philosophy is simple – we never rest on our laurels.
After years of systematic and extensive coverage in the Italian market, CDR has recently focused on perfecting its international markets and expanding its existing dealer network, with LEHIY Industrial representing CDR pumps with renewed enthusiasm.
CDRpompe's main products include: Cdrpompe pumps, Cdrpompe centrifugal pumps, Cdrpompe drive pumps, Cdrpompe mechanical seals, Cdrpompe acid and alkali centrifugal pumps, and Cdrpompe vortex pumps.
Main models include: UCL/UCL-B, UTS/UTS-B HE (I°FRAME), UTS/UTS-B HE (II°FRAME), UCS/UCS-B ETN series, UTN-L / UTN-BL series, UCN-L / UCN-BL series, UCS / UCS-B series, STN series, HTS series, and HTN series.
CDR Pompe brand introduction: CDR Pompe originated in the 1950s when founder Ferdinando Abordi acquired ARI Pompe, a family business specializing in cast iron pumps for home, agriculture, and industry.
Our main products include: CDR Pompe magnetic drive centrifugal pumps, CDR Pompe mechanical seal centrifugal pumps, CDR Pompe single-end mechanical seals, CDR Pompe double-mounted mechanical seals, CDR Pompe centrifugal pumps, and CDR Pompe shaftless magnetic pumps, which are suitable for chemical, industrial, pharmaceutical, air treatment, petrochemical, and water.
treatment industries.
Plain language sourcing guide for CDR pump UCL40-25-160 Italian CDRPompe centrifugal pump
Start with the full model name. Check the brand name. Check the part number. Check the code on the old unit. These small checks help you avoid a wrong order.
Take one clear photo of the front label. Take one photo of the side label. If the part has a cable, plug, port, seal, coil, or screen, take a photo of that area too.
Tell us the quantity you need. Tell us your country. Tell us the date when the plant needs the part. We can then check stock, lead time, safe packing, and the best shipping plan.
If the exact model is no longer made, do not guess. Send the old model and the use case. LEHIY can compare close options and explain which choice is safer for repair work.
Use simple order notes. Write the model in one line. Write the quantity in one line. Write the delivery country in one line. This helps our team reply faster.
Check the old part before removal. Look at the label. Look at the connector. Look at the mounting size. Look at the voltage or pressure rating if it is shown.
Do not rely on a short nickname for a part. Many industrial items have close versions. A small suffix can change the plug, output, range, or software setting.
Ask for a stock check if the plant is stopped. Ask for a lead time if the order is planned. Ask for packing photos if the part is fragile or heavy.
For a replacement order, tell us what failed. Tell us where the part is used. Tell us if an equal model is acceptable. This makes the first answer more useful.
For repeat orders, send the last invoice, old label, or old packing photo. The same reference can help us match the correct product again.
For urgent service, keep the message simple. One model, one quantity, one photo, and one delivery target are enough for a fast first check.
