Mitsubishi Electric module, Q64PN
LEHIY item code: LH-1249
*1 The so-called flashing OFF means repeating OFF and ON three times at 1-second intervals before entering the OFF (open circuit) state.
*2 When using Q61P-D in a system with an extension substrate, the POWER LED of Q61P-D on the extension substrate will turn a dark red light when the power is off, but there is no abnormality.
Technical Specifications Specification Value Power Supply Voltage (V) AC100~240V Rated Current (A) 8.5A/DC5V Brand Mitsubishi Electric Category Power Module: Specification.
Category: Power Module
Rated Current (A): 8.5A/DC5V
Quick buying check
This page helps you check Mitsubishi Electric module, Q64PN before you ask for a quote.
Confirm the brand, model number, part number, and quantity. Share a clear nameplate photo when the old item has close variants.
LEHIY can check stock, lead time, packing, shipping documents, and safe replacement options for maintenance orders.
Product Overview
| The power module provides DC 5V power to the various modules of the programmable controller mounted on the base plate |
Selection Data
Power Module | Q61P | Input Voltage: AC100～240V Output Voltage: DC5V Output Current: 6A |
Q62P | Input Voltage: AC100～240V Output Voltage: DC5/24V Output Current: 3A/0.6A | |
Q63P | Input Voltage: DC24V Output Voltage: DC5V Output Current: 6A | |
Q64PN | Input Voltage: AC100～240V Output Voltage: DC5V Output Current: 8.5A |
| The power supply module provides DC5V power to the various modules of the programmable controller mounted on the base plate |
Product Details
NO. | Name | Purpose |
1 | “POWER”LED*2 | Light on (Green): Normal (DC5V output, momentary stop within 20ms) Light off: ·AC power is ON, but the power module has malfunctioned. (DC5V abnormality, overload, internal circuit failure, fuse blown)·No AC power input ·Power outage (including momentary stops longer than 20ms) |
2 | “POWER”LED | On (green): Normal (DC5V output, momentary stop within 10ms) Off: ·DC power is ON, but the power module has failed. (DC5V abnormality, overload, internal circuit failure, fuse blown)·No DC power input ·Power outage (including momentary stops longer than 10ms) |
3 | “LIFE”LED | On (Green): When starting to use On (Orange): Module remaining lifespan approximately 50% Blinking (Orange): ·5 seconds on → 1 second off: Module remaining lifespan approximately 1 year ·0.5 second interval: Module remaining lifespan approximately 6 months Off: ·Reached the end of the module's lifespan ·Out of ambient temperature range (Module ambient temperature is above the specified value, and the lifespan detection function stops) On (Red): Out of ambient temperature range ( (When the module ambient temperature is above the specified value) Blinking (red): Functional malfunction (1-second interval) |
4 | ERR. Terminal | ·ON when the entire system is running normally. ·OFF (open circuit) when no power is input, when a CPU module stop-type error occurs (including reset), or when the fuse blows. ·OFF in a multi-CPU system configuration when a stop-type error occurs in any CPU module. Always OFF when mounted on an expansion board. |
5 | LIFE OUT Terminal | ·When the remaining lifespan is detected (less than 1 year), it becomes OFF (open circuit). ·When a lifespan diagnostic abnormality (including detection and processing abnormality) is detected, it becomes flickering OFF (open circuit). *1 ·When the ambient temperature range is exceeded, it becomes flickering OFF (open circuit). ·When the internal watchdog timer of the module is detected to be abnormal, it becomes OFF (open circuit). The above four actions may also occur when mounted on an expansion board. |
6 | FG Terminal | Ground terminal connected to the shielded part on the printed circuit board. |
7 | LG Terminal | Grounding of the power filter. With AC input, it has a potential of 1/2 of the input voltage. |
8 | +24V, 24G Terminal | Provides power to modules that require DC24V internal power (provided to the module via external wiring). |
9 | Terminal Bolt | M3.5 × 7 Bolt |
10 | Terminal Cover | Protective Cover for Terminal Block |
11 | Module Mounting Bolt Holes | Screw holes used to mount modules to the substrate. | M3 × 12 Bolts (User Supplied) (Tightening Torque Range: 0.36 ～ 0.48 N·m)
12 | Module Mounting Rod | Used when mounting the module onto the base plate. |
13 | Power Input Terminal | This is the power input terminal for Q61P-A1, connecting to AC100V AC power. |
14 | Power Input Terminal | This is the power input terminal for Q61P-A2, connecting to AC 200V AC power. |
15 | Power Input Terminal | This is the power input terminal for Q61P, Q61P-D, Q61SP, Q62P, and Q64PN, connecting to AC 100V to AC 200V AC power. |
16 | Power Input Terminal | This is the power input terminal for Q63P, connecting to a DC 24V power supply. |
17 | Power Input Terminal | This is the power input terminal for Q64P, connecting to an AC 100V/AC 200V power supply. |
*1 The so-called flashing OFF means repeating OFF and ON three times at 1-second intervals before entering the OFF (open circuit) state. *2 When using Q61P-D in a system with an extension substrate, the POWER LED of Q61P-D on the extension substrate will turn a dark red light when the power is off, but there is no abnormality. Technical Specifications
|
