MR-JE-40A Mitsubishi Servo Driver 400W Incremental Type
LEHIY item code: LH-0005
Quick buying check
This page helps you check MR-JE-40A Mitsubishi Servo Driver 400W Incremental Type before you ask for a quote.
Confirm the brand, model number, part number, and quantity. Share a clear nameplate photo when the old item has close variants.
LEHIY can check stock, lead time, packing, shipping documents, and safe replacement options for maintenance orders.
| MR-JE-A (Common Interface) Specifications | ||
| Servo Amplifier Model | MR-JE-40A | |
| Output | Rated voltage | Three-phase AC170V |
| Rated current [A] | 2.8 | |
| Power Input | Voltage, Frequency (Note) | Three-phase or single-phase AC200V ~ 240V,50Hz/60Hz |
| Rated current (note [A] | 2.6 | |
| Permissible voltage variation | Three-phase or single-phase AC170V ~ 264V | |
| Allowable Frequency Variation | Within ± 5% | |
| Power supply for interface | DC24V ± 10% (required current capacity: 0.3A) | |
| Control Mode | Sine wave PWM control, current control mode | |
| Allowable regenerative power silicon for servo amplifier built-in regenerative resistor 2,3) | [W] | 10 |
| Dynamic brakes | Built-in | |
| Communication function | USB: connection to a personal computer, etc. (corresponding to MRConfigurator2) | |
| Encoder Output Pulse | Corresponding (ABZ phase pulse) | |
| Analog Monitor | 2ch | |
| Position Control Mode | Maximum Input Pulse Frequency | 4Mpps (at differential pulse), 200kpps (at open collector) |
| Position feedback pulse | Encoder resolution (servo motor resolution per revolution):131072pulses/rev | |
| Command Pulse Rate | Electronic gear A/B times A = 1~16777215, B = 1~16777215, 1/10 & lt;A/B & lt;4000 | |
| Position in place range setting | Opulse ~ ± 65535pulses | |
| Excessive error | ± 3 revolutions | |
| Torque Limit | Parameter setting or external analog input setting (DCOV ~ +10V/maximum torque) | |
| Speed Control Mode | Speed control range | Analog speed command 1:2000, internal speed command 1:5000 |
| Analog Speed Command Input | DCOV ~ ± 10V/rated speed ([Pr.PC12] can be used to change the speed at 10V) | |
| Rate of Speed Change | less than 0.01 (load variation: 0% ~ 100), 0% (power supply variation: 10%) less than 0.2 (ambient temperature: 25 ℃ 10 ℃) only for analog speed command | |
| Torque Limit | Parameter setting or external analog input setting (DCOV ~ +10V/maximum torque) | |
| Torque Control Mode | Analog Torque Command Input | DCV ~ ± 8V/maximum torque (input impedance: 10kΩ ~ 12kQ) |
| Speed Limits | Parameter setting or external analog input setting (DCOV ~ ± 10V/rated speed) | |
| Servo function | Advanced vibration suppression control I, adaptive filter IIII, robust filter, automatic tuning, one-button adjustment, TOUGHDRIVE function, drive recorder function, equipment diagnosis function, power monitoring function | |
| Protection | Over current open circuit, regeneration over voltage open circuit, over load open circuit (electronic thermal relay), servo motor overheat protection, encoder abnormal protection, regeneration abnormal protection, under voltage protection, instantaneous power failure protection, over speed protection, excessive error protection | |
| Structure (degree of protection) | Self-cooling, open (IP20) | |
| Tightly fit | Live 5 | |
| Environmental conditions | Ambient temperature | Run: 0C ~ 55C (no freeze), Save:-20C ~ 65C (no freeze) |
| Ambient humidity | Run/save: below 90% RH (no condensation), save below 90% RH (no condensation) | |
| Air conditions | Indoor (no direct sunlight), no corrosive gas, flammable gas, oil mist and dust place | |
| Altitude | Altitude below 1000m | |
| Vibration | 5.9 m/s ², 10Hz ~ 55Hz(X,Y,Z directions) | |
| Weight [kg] | 0.8 |
Plain language sourcing guide for MR-JE-40A Mitsubishi Servo Driver 400W Incremental Type
Start with the full model name. Check the brand name. Check the part number. Check the code on the old unit. These small checks help you avoid a wrong order.
Take one clear photo of the front label. Take one photo of the side label. If the part has a cable, plug, port, seal, coil, or screen, take a photo of that area too.
Tell us the quantity you need. Tell us your country. Tell us the date when the plant needs the part. We can then check stock, lead time, safe packing, and the best shipping plan.
If the exact model is no longer made, do not guess. Send the old model and the use case. LEHIY can compare close options and explain which choice is safer for repair work.
Use simple order notes. Write the model in one line. Write the quantity in one line. Write the delivery country in one line. This helps our team reply faster.
Check the old part before removal. Look at the label. Look at the connector. Look at the mounting size. Look at the voltage or pressure rating if it is shown.
Do not rely on a short nickname for a part. Many industrial items have close versions. A small suffix can change the plug, output, range, or software setting.
Ask for a stock check if the plant is stopped. Ask for a lead time if the order is planned. Ask for packing photos if the part is fragile or heavy.
For a replacement order, tell us what failed. Tell us where the part is used. Tell us if an equal model is acceptable. This makes the first answer more useful.
For repeat orders, send the last invoice, old label, or old packing photo. The same reference can help us match the correct product again.
For urgent service, keep the message simple. One model, one quantity, one photo, and one delivery target are enough for a fast first check.
Share Article
| Brand Name: | Mitsubishi | Certification: | ISO9001, CE |
|---|---|---|---|
| Place of Origin: | China | Condition: | New |
| Warranty: | 1 year | Customized sourcing: | available |
What are your strengths?
Ans. LEHIY specializes in industrial automation and control components, offering fast sourcing, stable quality, and competitive prices for global customers.
What is your estimated delivery time?
Ans. Most items ship within 3-7 days. Customized or rare models may take 10-30 working days.
What are your primary product offerings?
Ans. Our main products include PLCs, sensors, valves, solenoid valves, actuators, power modules, transmitters, and complete industrial automation solutions.
How can I get in touch with you?
Ans. You can reach us anytime via Email, WhatsApp, LinkedIn, or our contact page. Our sales engineers respond quickly and provide technical support when needed.
What are your payment terms?
Ans. Standard terms are 50% TT in advance and 50% balance before delivery. We also support Alibaba Trade Assurance and L/C for qualified orders.
Feel free to Ask questions
Replacement support
MR-JE-40A Mitsubishi Servo Driver 400W Incremental Type
Send the brand, model, part number, quantity, nameplate photos, and application requirements. LEHIY will check availability, suitable alternatives, packing details, and delivery options before quoting.
For discontinued, temporarily unavailable, or configuration-sensitive items, our team can compare the requested model with close variants or compatible replacements for maintenance and spare parts planning.
Use this page as a practical sourcing note for engineers, buyers, and maintenance teams comparing automation components. Check the model name, brand, LEHIY code, application, and replacement requirements before sending an inquiry.
Short, clear information helps our team confirm availability faster and reduce back-and-forth communication during urgent maintenance projects.
- Confirm the complete model number and any suffix printed on the nameplate.
- Share quantity, destination country, preferred shipping method, and target delivery date.
- Include photos, drawings, old purchase records, or datasheets when compatible alternatives are acceptable.
- Ask for stock checking, replacement comparison, packing details, and export documentation before ordering.
Useful details for a faster quote
- Complete model and part number
- Required quantity and target delivery date
- Nameplate photos, drawings, or old purchase records
- Voltage, signal range, dimensions, or accessory needs
Model matching
We review brand, model, part number, nameplate photos, installation environment, and replacement requirements.
Quality and delivery
Each order can be checked for authenticity, condition, packing, warranty, shipping method, and delivery schedule.
Stock alternatives
For urgent maintenance projects, we can help check stock, compatible alternatives, and fast international shipment.
MR-JE-40A Mitsubishi Servo Driver 400W Incremental Type verification notes
Please send the full model number, quantity, target delivery date, and nameplate photos. These details help us check the requested product or a close replacement.
LEHIY reviews product name, part number, series, label information, and application requirements before shipment.
If the original model is discontinued or supplied with different accessories, we can explain practical differences before quoting.
For repeat purchasing, we can help organize related models, replacement parts, shipment schedules, and clear communication for your team.
