Endress+Hauser
E+H pH electrode CPS11D-7BA2G with signal cable CYK10
In Stock & ready to ship
The E+H pH electrode CPS11D-7BA2G, including signal cable CYK10-A051 (5 meters), is an explosion-proof E+H pH electrode CPS11D-7BA2G.
It needs to be used with explosion-proof cables and the E+H CM42 online analyzer in the following combination: E+H pH glass electrode; In-use equipment model or specification: CPS11D-7BA2G, including 5 meters of signal cable CYK10-A051; Used with the E+H CM42-MJA000EAZ00 online analyzer.
Basic parameters of the German E+H pH electrode CPS11D-7BA2G: Endershaus pH electrode CPS11D basic parameters: Model: CPS11D-7AA21; Measurement range: 1-12p; Product type: Industrial pH meter; Power supply voltage: 24V; Operating temperature: 0-135℃; Temperature compensation range: 25℃; Display method: Digital; Brand: E+H/Endershaus E+H pH Electrode CPS11D-7BA2G Detailed Description: The German E+H pH Electrode CPS11D-7AA21, an original Endershaus CPS11D pH meter, is a versatile electrode used in process and environmental engineering.
It provides reliable measurements even in high-concentration alkaline solutions or in hazardous areas. Its low maintenance and long service life design saves on electrode operating costs. Utilizing Memosens digital technology, the E+H pH Electrode CPS11D offers maximum process and data integrity while being easy to operate.
The electrode is corrosion-resistant and moisture-proof, allowing for laboratory calibration and equipment pre-maintenance.
The E+H pH electrode boasts advantages such as a large-ring PTFE diaphragm, robust electrode structure, low maintenance requirements, biocompatibility certification, a cross-shaped tube connection for a dual-chamber reference system, long electrode life, and a long toxicity diffusion path.
The process glass allows for the measurement of high-concentration alkaline solutions, with process pressures up to 16 bar (232 psi). Non-contact inductive signal transmission ensures maximum process safety. It stores sensor characteristic parameters and is easy to operate. The CPS11D-7AA21 E+H pH electrode CPS11D-7BA2G includes a 5-meter signal cable (CYK10-A051).
E+H pH electrode CPS11D-7BA2G technical parameters: pH measurement principle, glass electrode applications, standard applications in process measurement and environmental fields, long-term monitoring. Long-term monitoring of minute changes: Features include robust, heavy-duty construction; high pressure, built-in isoelectric terminal; flat septum measurement range: pH 0…14.
Measurement principle: integrated gel electrode with PTFE annular septum design; various sensor lengths; temperature sensor included. Advanced gel technology: Memosens digital electrode. Material: glass/PTFE. Dimensions: Diameter: 12 mm (0.46 inch); Sensor rod lengths: 120 mm (4.68 inch), 225 mm (8.77 inch), 360 mm (14.04 inch), and 425 mm (16.57 inch). Process temperature max.
135 °C (274 °F). Process pressure max. 16 bar (230 psi). Temperature sensor: NTC 30k. Explosion-proof certification (Ex): ATEX FM CSA. Connection: Inductive digital Memosens connector. Protection rating: IP68. Other certifications: Biocompatibility SIL certification provided.
Share Article
| Brand Name: | Endress+Hauser | Certification: | ISO9001,CE |
|---|---|---|---|
| Place of Origin: | China | Condition: | New |
| Warranty: | 1 years | Customized design: | available |
